FC&FC Blue Cord Port 5M Duplex Optical Cable Patch Cord Simplex SM FTTH 3M 5M For WLAN Survilance

FC&FC Blue Cord Port 5M Duplex Optical Cable Patch Cord Simplex SM FTTH 3M 5M

Anti-rodent fiber optic cable is built in a stainless steel cover that can protects the jumper cable from open circuits, short circuit, and other damage due to rats in restaurants, fast food establishments, shops, warehouses, and so on.

With FC to SC connectors, this fiber patch cable is ready for deployment in any single-mode 9/125 network. Singlemode 9/125 are best used for long cable runs. This singlemode fiber cable is comprised of optical fiber with ceramic connectors. The connectors utilize a UPC (Ultra Physical Contact) polish which provides a better surface finish with less back reflection. It has a yellow, riser rated, PVC, zipcord jacket.

Specification:

Connector type: SC to SC

Fiber type: Single mode

Insertion Loss:<0.3dB

Operating Wavelength:1310nm-1550nm

Cable diameter:3mm

Minimum bend radius:3.8cm

Plug: ceramic ferrule

Material:PVC,Stainless Steel

Insertion and removal times: >1000 times

Working temperature: -40°C~85°C

Tensile strength: ≥200N

Vibration : <0.1db

Jacket: OFNR (Riser-Rated)

Features:

Low insertion loss and back reflection loss

Good repeatability

Good exchangeability

Good Durability

Interpolation performance is good

High temperature stability

Immune to Electrical Interference

100% Optically Inspected and Tested for Insertion Loss

Application:

Optical LAN

Optical fiber communication systems

Test equipment

Fiber CATV

Fiber Network Deployments

Fast Ethernet

Gigabit Ethernet

Other Data Applications Requiring High Transfer Rates
