| Brand Name: | monoluxtecs |
| Model Number: | TS0019 |
| MOQ: | 100PCS |
| Price: | negotiable |
| Packaging Details: | Custom packaging、PE bag |
| Payment Terms: | L/C, D/A, D/P, T/T, MoneyGram, Western Union |
TOSLINK Optical Audio Cable OD5.0 Blakc Knite Rope Plated Alloy Shell Gold Interface 0.8M 1.2M For Home Theatre Soundbar
Technical parameter:
Product name: TOSLINK Audio Optical Cable
Commodity brand:monoluxtecs
Commodity number: CD-1001
Product color: black
Core diameter (mm):Ø1.0
Wire diameter (mm):Ø5.0
Exterior:Black PE coating
Operating temperature:-55℃～+70℃
Connector model:Tosllink connector is connected to the clamping structure
Transmission loss (wavelength: 650nm) 180～200dB/km
Insertion loss (wavelength: 650nm) Max: 1.0dB
Interchangeability Max: 1.0dB (random transformation)
Minimum bending radius:25mm
tensile strength:Max: 1.0dB (0～70N)
Vibration test: Max: 1.0dB (5～50Hz, 1.5mm amplitude)
Advantages of fiber optic cable:
& TOSLINK is a standard optical digital audio interface that Japanese manufacturers generally use on CD players and MD players.
& It is used to transmit digital audio signals (left and right channels or multi-channels) through a kind of light conductor and light as a carrier between various equipment.
& This fiber optic cable is specially developed for HI-FI audio system and home theater system. It is a good choice for digital home theater audio transmission with new Dolby AC3 and DTS surround technology.
& The special structure of the outer layer of the wire can eliminate all high-frequency electromagnetic interference.
Scope of Application:
1: Audio connection between DVD, CD player and amplifier;
2: Audio connection between computer and power amplifier;
3: Connection between PS II, PSIII, HDVD and power amplifier;
4: Audio connection between digital TV set-top box and power amplifier;
|
|
