Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m

Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m

Brand Name: monoluxtecs
Model Number: QH-SM127
MOQ: 100PCS
Price: negotiation
Packaging Details: Carton, PE, Customized
Payment Terms: L/C, D/A, D/P, T/T
Detail Information
Place of Origin:
Shenzhen
Certification:
Rohs, ISO9001
Usage:
Industrical Sensor
Theory:
Optical Sensor
Output:
Switching Transducer
Material:
Stainless Steel
Condition:
Original
Color:
Original Color
Operating Voltage:
12~24VDC
Shell Material:
ABS
Supply Ability:
500PCS + 1 WORK DAYS
High Light:

Optic Fiber Sensor 1m

,

Diffuse Reflection optical fiber sensor

,

corrosion resistance optical fiber sensor

Product Description

Optic Fiber Sensor Diffuse Reflection &M3/M4/M5 Series Connector Antenna 0.8mm 1M



Compared with traditional sensors, optical fiber sensors have unique advantages:



(1) High sensitivity

Due to the small diameter of the optical fiber used, the optical length will change when subjected to a small mechanical force or temperature change, resulting in a larger phase change.



(2) Anti-electromagnetic interference, electrical insulation, corrosion resistance, intrinsically safe

Because the optical fiber sensor is the use of light wave transmission information, and the optical fiber is electrical insulation, corrosion resistant transmission medium, and safe and reliable, which makes it can be conveniently and effectively used in a variety of large electromechanical, petrochemical, mine and other strong electromagnetic interference and flammable and explosive environment.



(3) Fast measurement speed

Light is the fastest and can carry two-dimensional information, so it can be used for high-speed measurements. The analysis of radar and other signals requires a very high detection rate, which is difficult to be achieved by using the method of electronics, so it can be solved by using the high-speed spectral analysis of the diffraction phenomenon of light.



(4) Large information capacity

The measured signal is carried by light wave, which has a very high frequency and a wide frequency band. The same optical fiber can transmit multiple signals.



(5) Suitable for harsh environment

Optical fiber is a kind of dielectric, high pressure resistance, corrosion resistance, electromagnetic interference resistance, can be used in other sensors are not adapted to the harsh environment.



In addition, optical fiber sensor also has the characteristics of light weight, small size, winding, wide measurement objects, good reuse, low cost.





Model QH-SM125 FRE-310-l FRE-310-S15 FRE-310-S FRE-310-M
Fiber Material plastic
Fiber Size fiber core 0.25mm*2 / outer diameter 1.0mm
Detection Distance 0-50mm, the higher the accuracy, the closer the detection distance
Min. object Ф 0.1mm

Thread Probe

Mate rial

Stainless Steel

Thread Probe

Size

M3X18mm
Needle Ф0.8X5mm Ф0.8X10mm Ф0.8X15mm Ф0.8X20mm Ф0.8X40mm
Cable Length 1m / 2m (more to customize)



Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m 0

Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m 1





Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m 2Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m 3Diffuse Reflection Optical Fiber Sensor M3/M4/M5 Series Connector Antenna 0.8mm 1m 4
