Product Details:
|
Model Number: | ST-ST Duplex Patch Cord | Certification: | ISO9001 |
---|---|---|---|
Insertion Loss: | < 0.3db | Type: | Coaxial,Single-Mode Or Multi-Mode |
Connector Type: | ST Connector | Ferrule: | UPC APC |
Jacket Material: | LSZH | Package: | Plastic Bag,Carton,1km/roll |
Name: | Ftth Drop Cable, Illuminate Optic Cable | Color: | Orange Or Customzied |
ST to ST Industrial plastic optic patch cord POF Fiber Patch Cords ST/ST Connector
The ST-ST Plastic Optical Fiber (POF) Patch Cord is specifically designed for industrial control and automation systems requiring reliable, interference-free data transmission. Constructed with robust plastic optical fiber and secure ST connectors, it ensures high-performance communication in harsh environments, including areas with high EMI or vibration.
Technical Specifications:
Connector Type: ST to ST (Bayonet-style for secure mechanical connection)
Fiber Type: Step-index Plastic Optical Fiber (POF)
Core/Cladding Diameter: 1.0 mm / 2.2 mm
Fiber Material: PMMA (Poly(methyl methacrylate)) core with fluoropolymer cladding
Cable Jacket Material: PE / PVC / LSZH (optional for flame-retardant or halogen-free requirements)
Transmission Wavelength: 650 nm (optimized for red LED sources)
Attenuation: ≤ 0.2 dB/m @ 650 nm
Typical Transmission Distance: Up to 50 meters
Insertion Loss: ≤ 1.0 dB (typical)
Return Loss: ≥ 20 dB
Operating Temperature: -40°C to +75°C
Minimum Bend Radius: ≥ 25 mm
Mechanical Durability: >1,000 mating cycles
Cable Length: Standard or customized (1 m – 100 m)
Key Features:
High EMI/RFI Immunity: Ideal for noisy industrial environments
Secure ST Connectors: Locking bayonet design ensures stable connection under vibration
Flexible & Durable: Withstands bending, pulling, and industrial wear
Easy to Install: Plug-and-play design with no need for special tools
Reliable Data Transmission: Stable signal over short to medium distances
Customization Available: Jacket type, length, and labeling per customer requirements
Applications:
PLC and sensor communication
Factory automation networks
Robotics and machine vision systems
Industrial Ethernet over POF
EMC-sensitive environments
